High Pressure Oil-Free
For filling cylinders with pure gases or clean mixtures at high pressure (3,000 psig+), or filling accumulators at intermediate pressures (400 psig-), or other applications requiring water-cooled or air-cooled compressors, for small flows (from 0.1 Nm3/h) or large flows (up to 6,400 Nm3/h), Oxytek has the solution or develops it upon request. The most in-demand models are:
| Model | Gas | Flow (Nm3/h) | Inlet Pressure Min (psig) | Outlet Pressure Max (psig) |
|---|---|---|---|---|
| Microboost | O2 |
0.1–0.45 |
3 |
2,200 |
| 2PS | O2 |
0.8–3.2 |
30 |
2,200* |
| 2T | O2, N2, H2, He, CH4, others** |
11–48 |
29 |
435 |
| 2V3 | O2, others** |
6–16 |
3 |
3,000 |
| 4V4 | O2, N2, H2, He, Ar, CO2, mixtures, others** |
16–26 |
5 |
3,000 |
